Performance Features
1. The bottle washing machine adopts mechanical hands to clamp the
bottles, suitable for vials of various specifications.
2. The water-gas spray needles adopt the reciprocating tracking
insertion mode for bottle washing, featured by good washing effect
and energy saving, It is also provided with a device that prevents
the needle holder from shaking to enhance the accuracy of the spray
needle' s insertion into the bottle and reduce the occurrence of
needle breakage.
3. The water and gas pipes are totally separable from the spray
needles, s0 that across contamination is avoided and GMP
requirements are met.
4. The buffer block is installed before the bottle discharging
screw of the bottle washing machine to protect the screw and reduce
bottle breakage.
Bottle discharging is realized by the integral imported synchronous
belt that is connected to the bottle pushing block and conveys
ampoules with stable and reliable running.
5. The oven adopts hot air circulation heating with even
temperature and energy saving.
6. The oven is provided with the function of protecting against
sudden power-off to ensure safe running.
7. The oven can be equipped with the circulation water cooling
device that does not consume wind volume in the room, reduces the
8. The oven can be equipped with the differential pressure
automatic balancing and regulating system to reduce the problems of
deviation at the high temperature section caused by unbalanced
differential pressure in the room and oven, temperature rise in the
filling room, washing and drying room, etc.
9. The oven is provided with DOP inspection ports (including
inspection ports for wind pressure, wind speed and dust particles).
10. The cooling section in the oven is provided with the seriation
function (specially chosen by FDA).
11. The oven mesh belt can be equipped with the ultrasonic and CIP
cleaning systems.
12. The filling machine adopts the world's most advanced design
concept, featured by high speed, accurate filling and convenient
13. The filling machine adopts the AC servo motor to drive the
filling screw to tum with accurate filing volume., The adjustment
of filling volume of the filling machine can be realized through
the touch screen.
14. The filling machine can be equipped with the 100-grade
circulation laminar flow hood.
15. The filling machine is provided with the functions of no
filling in case of no bottle and no stoppling in case of no bottle
Main Technical Parameter
Product model | KFG/Q | KFG/L |
Scope of use | 1-30ml |
Production capacity | 250(2 heads) | 400(4 heads) |
Bottle washing pass rate | ≥99.9% |
Bottle washing breakage rate | ≤0.1% |
Sterilization temperature | 300-350 |
Filling error | ≤±3.0 |
Stoppling pass rate | ≥99.9% |
Air laminar flow cleanliness | 100% |
Vacuum pumping speed | 25m3/h | 50m3/h |
Capacitance | 96 | 235.5 |
Power supply | 380V | 50Hz |
Total weight | 8200kg |
