Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers

    Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers
    • Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers
    • Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers
    • Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers
    • Buy cheap Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine from wholesalers

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Ask Lasest Price
    Brand Name : XHL
    Certification : GMP
    Supply Ability : 10 Set/Sets per Month
    Price : $19,999.00 - $49,999.00 / Set
    Model Number : YGS12/8
    Payment Terms : L/C, T/T
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    XHL-YGS12/8 Automatic Honey Filling Machine For Round Bottle

    Product Description

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine


    Our Factory


    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling MachineRound Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine


    Our Warehouse


    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine


    Why choose us?


    1. 17 years manufacture in filling line and machine
    2. 2 years alibaba supplier
    3. 100% QC inspection before shipment
    4. 12 months warranty
    5. Product Certificated by CE, ISO

    Overview

    The YGS linear filling and cap turning (capping) integrated machine is a new product developed by our company after introducing internationally advanced technology to meet market demand. The machine adopts the 31 6L stainless steel plunger metering pump to perform filling, and combines automatic cap feeding and automatic cap turning(capping)with mechanical, electrical and pneumatic integration. It is economical and practical, taking small floor space. It is widely used for liquid packaging in such industries as medicine, food, pesticide, chemical industry, cosmetics, etc., fully conforming to GMP requirements.


    Main Performance features


    -Integrating filling and cap turning (capping) and taking small floor space. With servo driving, the filling volume is adjusted on the man-machine interface, featured by convenient operation and quick adjustment.

    - It adopts the plunger metering pump to fill liquids of various viscosities with high precision. The pump can be easily disassembled, making cleaning and sterilization convenient. It can be equipped with CIP/SIP cleaning and sterilization system.- The seal ring of the plunger metering pump is made of silicon rubber, Teflon or other materials depending on different industries and liquid ingredients. Ceramic material can be used in special applications. The fling principle also includes the use of peristaltic pump, negative pressure type, weighing type, self-flow type, reflux defoaming type, etc.

    - PLC control system with variable frequency speed control and high degree of automation.

    - The filling system is provided with the anti-leaking device, realizing filling from the bottom of the bottle, rising slowly and avoiding bubbles.

    - The tightness of the air gripper type cap turning head can be adjusted without damaging the bottle and cap. It can be equipped with servo motor driving with adjustable torque. The capping head adopts flexible design with easy adjustment, and can also be designed to be used for pull caps.

    -It can be equipped with the cap storage and lifting mechanism and the mechanism for identifying reverse caps and eliminating nonconforming products.

    -The whole machine is suitable for various specifications of bottles and adjustments can be completed conveniently within a short time.

    - The whole machine is designed according to GMP requirements.

    Main Technical parameters


    Product modelYGS16/8YGS12/8YGS8/4YGS6/1YGS4/1

    Number of filling heads

    1612864

    Number of cap turning and pressing heads

    88411

    Filling speed bottles/min

    100-12090-12060-8045-5040-50

    Filling range

    20-1000ml

    Ideal Filling range

    20-500ml

    Optional cap type

    Anti-theft cap, screw cap, Ropp aluminum cap

    Filling accuracy

    ≤±0.5-1%

    Cap turning and pressing pass rate

    ≥99.8%

    Power supply

    220V 50/60HZ

    Power

    ≤2.2kw≤2.2kw≤1.2kw≤1.2kw≤1.2kw

    Compressed air

    0.4-0.6Mpa

    weight

    2000kg2000kg1200kg1000kg800kg

    Outline dimensions(mm)

    3600*1000*

    1800

    3600*1000*

    1800

    3000*1000*

    1800

    2800*1000*

    1600

    2500*1000*

    1600


    Our Partner

    Round Bottle 1000ml 5400BPH High Viscosity Liquid Filling Machine


    Our service and warrantee


    1.We can customize the machine as customer requried ;
    2.Available for OEM/ODM service ;
    3.Offer living broadcast or video support;
    4.To Door installation and training service ;
    5. Offer filling line solution with customer required
    6.Customer’s design are welcomed.


    We can customize with your packaging materials, production capacity and demands. We will provide you with associated design solutions and case videos.
