Company Profile
Founded in 2003, Jiangsu Winlong Pharmaceutical Machinery Co., Ltd.
(stock code:836556), formerly known as Jiangsu Winlong Filling
Machinery Co.( Ltd., is located in Jintan District, Changzhou City,
Yangtze River Delta Economic Development Zone. Mainly engaged in
providing overall solutions for smart workshops in pharmaceutical,
biological, health product and daily chemical industries and
manufacturing, selling, importing and exporting other packaging
machinery products, it is a high-tech enterprise and a member unit
of China Association for Pharmaceutical Equipment.
It is an important strategic objective of Winlong to participate in
international competition and become stronger and more specialized.
Our company attaches great importance to independent innovation, so
that our product technology and quality stand at the forefront in
the industry in China. With advanced technological innovation
capacity and well-trained personnel, it provides domestic and
foreign customers with overall individualized solutions for
automatic production of many packaging production lines. In
addition, it has also been granted a number of patents for
invention. While actively responding to “Made in China 2025” and
promote the industry 4.0 system engineering project, we are
creating value for customers.
Our Factory
Our Warehouse
Why choose us?
1. 17 years manufacture in filling line and machine2. 2 years alibaba supplier
3. 100% QC inspection before shipment
4. 12 months warranty
5. Product Certificated by CE, ISO
Overview
The production line is composed of QCLW ultrasonic bottle washing
machine, HX tunnel sterilization dryer, KZYG oral liquid filling
and capping machine, PWX bottle external washing dryer, lamp
inspection machine, labeling machine, feeding machine, cartoning
machine, weighing machine, case packing machine and palletizer. It
is mainly used for ultrasonic washing,water-gas alternate jetting
washing and high temperature hot air sterilization of oral liquid
bottles, as well as filling, capping and back- end-of-line
packaging of liquid medicines. The production line inherits
intemationally advanced technology inits structural principle, and
incorporates various patented technologies with independent
intellectual property rights,conforming to the new version GMP
requirements. It hasreached the advanced level and can replace
similar imported products.
Main Performance features
- Applicable specifications: 5- 20ml
- Filling accuracy: conforming to " Inspection Standardof Visible
Particles in Chinese Pharmacopoeia"
0.5%
- Clarity: conforming to "Inspection Standard ofVisible Particles
in Chinese Pharmacopoeia"
- Product pass rate: 99.9%
- Purified water: 0.4-0.5MPa 50'C 0.9m3/h
- Compressed air: 0.4-0.5MPa ~60m3/h
- Machine noise: conforming to the standard
- Operator: 2- 5 persons (including back-end-of-linepackaging)
- Dimensions: See the schematic diagram
Main Technical Parameters
| Equipment composition | Bottle washing drying Filling and pressing | QCLW/80 HX420/4500 KZ10-12/16 | QCLW/100 HX620/6500 KZYG16/24 | QCLW/120 HX920/6500 KZYG24/24 |
| Stable production capacity | 5ml | 18000bph | 24000bph | 33000bph |
| 10ml | 18000bph | 24000bph | 33000bph |
| 20ml | 12000bph | 18000bph | 24000bph |
| Number of bottle washing heads | 80 heads | 100 heads | 120 heads |
| Number of filling and pressing heads | 12 heads | 16 heads | 24 heads |
| Number of capping heads | 16 heads | 24 heads | 24 heads |
| Power | 50 kw | 63 kw | 88 kw |
| Exhaust volume | 1800m3/h ±20% | 2400m3/h ±20% | 3000m3/h ±20% |
| Weight | 5900kg | 6900kg | 8900kg |
Our Partner
Our service and warrantee
1.We can customize the machine as customer requried ;
2.Available for OEM/ODM service ;
3.Offer living broadcast or video support;
4.To Door installation and training service ;
5. Offer filling line solution with customer required
6.Customer’s design are welcomed.
We can customize with your packaging materials, production capacity
and demands. We will provide you with associated design solutions
and case videos.
