    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    Ask Lasest Price
    Brand Name : XHL
    Price : $2,888.00 / Set
    Model Number : H331R
    Certification : ISO9001;CE;RoHS;TUV
    Payment Terms : L/C, T/T
    Supply Ability : 10 Set/Sets per Month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    XHL-H331R Desktop R-rotatable Single Station Automatic Soldering Machine

    Quick Details

    Place of Origin:Guangdong, China (Mainland)

    Brand Name:XHL Technology

    Condition:New

    Work Area:300(x)*300(y)*100(z)mm R-axis:360°

    XYZ Repeatability:±0.03mm

    Certificate:ISO9001

    After-sales Service Provided:Field installation, commissioning and training, Video technical support, Online support, Overseas third-party support available

    Supply Ability

    300sets/per month

    Packaging & Delivery

    Strong wooden cases suitable for a long distance shipment.

    package weight :about 45kg

    package size: about 700(L)*700(W)*950(H) mm

    Port:Shenzhen

    Parameter:

    Product Model

    XHL-H331R

    XHL-H441R

    XHL-H551R

    XHL-H661R

    Operating Range

    X-axis

    300mm

    400mm

    500mm

    600mm

    Y-axis

    300mm

    400mm

    500mm

    600mm

    Z-axis

    100mm

    100mm

    100mm

    100mm

    R-axis

    360°

    360°

    360°

    360°

    Dimensions(mm)

    L

    516

    616

    716

    816

    W

    585

    685

    716

    816

    H

    800

    800

    800

    800

    Weight

    35kg

    40kg

    50kg

    55kg

    Maximum Speed

    300mm /S(Maximum customizable 800mm)

    Repeatability

    ±0.02mm-0.05MM (Customizable within ±0.02mm)

    Control System

    independent research and development

    Driving Mode

    Precisely Stepping Motor+Timing belt+Taiwan brand linear guide

    Program Storage

    It can store one thousand sets of processing data and a single processing file can occupy up to 3M storage space (five thousand processing points)

    File Storage Space

    Handheld box 256M, offline card 32M, single processing file up to 3M storage space (100,000 processing points)

    Support Document

    CAD,CorelDRAW

    power supply

    AC220V 50 – 60HZ 350W(Selectable)

    Temperature control range

    0-550C°

    Iron Tip Cleaning

    Air cleaning/Pneumatic

    Control Panel

    Teach pendant

    External Interface

    USB + RS232

    Soldering Method

    Point Soldering/Drag Soldering

    Working Temperature/
    Humidity

    5-40C°
    /20-90% RH

    Brief introduction

    Automatic soldering machine is mainly used in electronics manufacturing, mainly for reflow soldering, wave soldering and other production equipment.
    This machine is suitable for difficult process and solder processing. It is especially suitable for welding of mixed circuit boards, heat sensitive components and sensitive devices in SMT back-end process. It is widely used in PCB soldering wire, charger plug soldering and connector welding, DC terminal tinning, LED light strip connection and other fields. Automatic soldering robots replace manual welding to improve work efficiency and improve welding quality.

    Product Feature

    1.Flexible and diverse soldering method, with spot welding, drag welding (pull welding) and other functions.
    2.The mechanical arm of the equipment is made of aluminum, no deformation, no rust, stable operation.
    3.Device writing work program can perform point-to-point, block-to-block copying and shorten programming time.
    4.The device has an automatic cleaning function, which stabilizes the quality of solder processing and extends the service life of the soldering iron tip to a certain extent.
    5.Multi-axis linkage manipulators, all using precision stepper motor drive and advanced motion control algorithms to effectively improve motion positioning accuracy and repeatability.

    Application

    Suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries,Connector, RJ/network transformer, cable, FPCB soldering, COF soldering, computer motherboard,High quality welding such as CABLE, horn and motor.

    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    Desktop 360° R Axis AC220V Glue Dispensing Equipment

    How to program it? How to use it?
    (Operating system that can be switched between Chinese and English)

    1. Open Programing Box. in the program screen
    2. Move X,Y,Z button to adjust
    3.Use the Iron head as the base point to align the key position of the product, press the enter key, the program will automatically generate this point in the system,then setting the data about the point and so on.

    Packaging & Shipping

    Strong wooden cases suitable for a long distance shipment.
    package weight :about 45kg
    package size: about 700(L)*700(W)*950(H) mm

    Our Services

    1.We can make part design and mould design by software CAD,UG,PRO/E,Solidworks and Catia ect

    2.Available for OEM/ODM service and very super precision reachs to 0.001mm.

    3.Standard mould base.

    4.Send sample with test video to customers for check product quality and mould working condition.

    5.During the period of making the mould,we’ll report the process of the mould with pictures every Monday.

    6.Customer’s design are welcomed.

    7.Competive price with on-time delivery.

    8.One year warranty.
