XHL-H331R Desktop R-rotatable Single Station Automatic Soldering
Machine
Quick Details
Place of Origin:Guangdong, China (Mainland)
Brand Name:XHL Technology
Condition:New
Work Area:300(x)*300(y)*100(z)mm R-axis:360°
XYZ Repeatability:±0.03mm
Certificate:ISO9001
After-sales Service Provided:Field installation, commissioning and training, Video technical
support, Online support, Overseas third-party support available
Supply Ability
300sets/per month
XHL-HZ331 Intelligent CCD Vision glue dispenser machine
Applications: bonding, filling, coating, sealing, filling, drip,
linear/arc/circular gluing, etc.
Products Features :
1. Hot melt glue dispensing machine has the functions of drawing dots, lines, arcs, circles,
continuous tween input program of irregular curves and
three-dimensional dispensing
2. Continuous dispensing function of arbitrary points, lines,
surfaces, arcs and other irregular curves
3, high speed, low noise speed brushless dc motor to make the
dispensing better
4. Electrostatic eliminator can eliminate static electricity within
±100V
5. Automatic dispensing strength compensation function makes
operation more convenient
6. XY area array, translation and rotation operation function,
reverse use of stock plate, suitable for different work positioning
7. Support three-axis space linear interpolation, three-axis space
arc interpolation and elliptic arc interpolation
8. Support the import function of computer graphics, including PLT
files, TCF files and G code files
Parameter
| XY Speed | Max: 200mm/s |
| Drive Mode | Japan Xinnong Motor / Taiwan HIWIN slide rail |
| XY accelerated speed | Max: 0.5g |
| Z speed | Max: 0.3g |
| XYZ Repeat accuracy | ±0.02mm |
| Glue dispenser vision position system |
| Vision Sense | |
| Illuminant | LED illuminant |
| Glue dispenser area |
| Max area | X300*Y300mm |
| Max height | Z100mm |
| Z Axis load | 6.5KG |
| Control System |
| Computer | Industrial computer, liquid crystal display, keyboard and mouse |
| Operation system | Windows |
| Control software | Independent innovating |
| Liquid feed | 30CC Injection |
| Dispenser valve | High speed dispenser valve |
| Power | AC220V, 50/60HZ, 1.5KW |
| Air-pressure | 0.5-0.7Mpa, 0.1m3/h |
| Machine weight | 85kgs |
| Machine volum | L690*W728*H680mm |
How to program it? How to use it?
(Operating system that can be switched between Chinese and English)
1. Open Programing Box. in the program screen
2. Move X,Y,Z button to adjust
3.Use the Iron head as the base point to align the key position of
the product, press the enter key, the program will automatically
generate this point in the system,then setting the data about the
point and so on.
Packaging & Shipping
Strong wooden cases suitable for a long distance shipment.
package weight :about 45kg
package size: about 700(L)*700(W)*950(H) mm
